All-in-One integrated technology: PCs, inverters, BMS, and EMS
Battery compartment: Lithium Iron Phosphate (LFP) battery with aerosol fire-extinguishing solution
More support: Support storing energy from diesel generator,wind and PV
Safety features: combustible gas, smoke, and temperature detection, active exhaust, and fire alarm
Constant temperature and humidity: Intelligent constant temperature and humidity system ensures safe and efficient charging and discharging of batteries
All In One Solar Storage Cabinet 30kW 60kW 100kW 61kWh 112kWh 241kWh Lithium Battery System【All-in-One ESS】
Product Features
-
Perfect
Compatibility
-
Fast
Installation
-
Premium
Cell
-
Long Life
8000 cycles
Application Scenarios
Related Data
Connect Diagram

Model | VN-AES30-HC61 | VN-AES60-HC112 | VN-AES100-HC241 |
System Specification | |||
Rated Output Power | 30kW | 60kW | 100kW |
System Capacity | 61.44kWh | 112.5kWh | 241.15kWh |
Battery Type | LiFePO4 | ||
Battery Rated Voltage | 614.4V | 358.4V | 716.8V |
Battery Voltage Range | 508.8 – 691.2V | 296.8 – 403.2V | 593.6 – 806.4V |
Switching Time between On and Off Grid | <10ms | ||
Scalability | 15 | 7 | 8 |
Altitude | 4000m (>2,000 Derating) | ||
Ingress Protection | IP54 | ||
Humidity | 5% – 95% | ||
Size(L×H×D) | 1450×2070×1212mm | 1450×2070×1212mm | 1866×2290×1212mm |
Weight | 1.0T | 1.5T | 2.5T |
Design Life | 10 years | ||
Warranty | 5 years | ||
Battery Technical Specification | |||
Battery Module Model | 3.2V/100Ah | 3.2V/314Ah | 3.2V/314Ah |
Connection Method | 1P192S | 1P112S | 1P240S |
Battery Cluster | 614V/100Ah | 358.4V/314Ah | 716.8V/314Ah |
Max. Charging/Discharging Current | 50A | 157A | 157A |
Operating Temperature Range | Charge -20 – 55°C; Discharge 0 – 55°C | ||
Cycle Life | >8000cycles | ||
Inverter Technical Specification | |||
Max. PV Input Power | 38.4kW | 76.8kW | 120kW |
Max. PV Input Current | 64A | 128A | 200A |
Max. PV Input Voltage | 850V | 850V | 950V |
No. of MPPT Trackers | 2 | 4 | 4 |
MPPT Voltage Range | 200 – 800V | 200 – 950V | |
Start – up Voltage | 250V | ||
Rated Grid Frequency | 50(47Hz – 52Hz)/60Hz | ||
Rated Grid Voltage | 380V/400V | ||
Communication | RS485/WiFi/4G |
Hefei VoltaNest Energy Storage Technology Co., Ltd.
VoltaNest is located in Hefei City, Anhui Province. As a global leading new energy enterprise, with over 20 years of experience in PV systems, VoltaNest Group provides high-quality energy storage products for residential, commercial, and utility applications. Our lithium iron phosphate (LFP) solar battery systems offer safe, long-lasting, and efficient energy storage.
VoltaNest has won the unanimous recognition of consumers with satisfactory quality and perfect after-sales service. We can provide customized services and overseas installation services according to the needs of different customers.We can provide customized products according to customer needs. ODM and OEM orders are welcome.

Our products are all packed in cartons or wooden boxes that meet international standards, and we ensure that all products can reach customers safely and quickly. We also support video inspection, which makes the whole process transparent and gives customers more peace of mind.
Our products have UL, CE, UN38.3, IEC62619, MSDS and other certifications

FAQ
Q: Can you provide shipping services?
A: Yes, we can handle customs clearance and door-to-door delivery.
Q: If I have my own brand and would like custom manufacturing services, would you be able to do that?
A: We are a leading energy storage battery manufacturer in China, providing OEM/ODM services to over 58 partners worldwide.
Q: How to install and use?
A: We provide installation and operating instructions and video tutorials, and we also offer overseas installation services upon request.
Q: What if I encounter problems during use?
A: Our products come with an extended 5-10 year warranty and a lifetime free diagnostic service.
Q: Can I become a local distributor for your products?
A: We will evaluate the distributor’s capabilities and provide financial, product, and technical supp
