    VN-50K-CH200 C&l Outdoor Integrated Cabinet
    VN-50K-CH200 C&l Outdoor Integrated Cabinet
    Datasheet

    50kW 200kWh High Voltage Lithium Battery Energy Storage Cabinet【All-in-One ESS】

    High Capacity: 200kWh energy storage using LiFePO4 batteries
    Powerful Output: 50kW rated power
    Advanced Safety: Integrated fire suppression and comprehensive electrical protection
    Smart Connectivity: Supports RS485, Modbus TCP for seamless integration and monitoring
    Durable Design: IP54 rated enclosure for demanding environments
    Flexible Installation: Suitable for indoor applications
    Reliable Operation: Designed for long-lasting performance and stability

    Inquire Now
    contact us

    Share:

    Product Features

    • Supports Photovoltaic Access

    • Modular design for flexible expansionand easy maintenance.

    • Multiple communication methods support remote upgrades.

    • Supports 100% unbalanced loads and 110% long-term overoads.

    • Ultra-high energy density, compactsize, easy installation and transportation.

    • Adjustable output power, configurable charge and discharge power,strong grid adaptabilit.

    Application Scenarios

    Related Data

    ModelVN-50K-CH200
    Battery Parameters
    Usable Energy20.0kWh
    Battery TypeLFP(LiFePO₄)
    Cell Module Capacity4.333kWh
    Number of Battery Modules5
    Rated Battery Voltage798V
    Max. Charge/Discharge Current140A
    PV Input Parameters
    Max. Input Power60kW
    Max. Input Voltage1000V
    MPPT Voltage Range150-850V
    Startup Voltage180V
    Rated Input Voltage600V
    Max. Input Current per MPPT5A
    Max. Short-circuit Current per MPPT5.5A
    Number of MPPTs4
    Number of Strings per MPPT2
    Grid-tied Output Parameters
    Rated Output Power50kW
    Max. Output Power55kW
    Rated Output Apparent Power50kVA
    Rated Output Voltage400/380V
    Output Voltage Range320-456V
    Max. Grid-tied Output Current72.5A
    Max. Input Current79.8A
    Power Factor~1
    Total Current Harmonic Distortion<3%
    Off-Grid Output Parameters
    Rated Off-Grid Apparent Power50kVA
    Max. Off-Grid Apparent Power55kVA
    Rated Output Current79.8A
    Max. Output Voltage400/380V
    Output Voltage Range310-456V
    Total Current Harmonic Distortion<3%
    Efficiency
    Max. PCS Efficiency98.00%
    System Efficiency95.00%
    Protection
    PV Reverse Polarity ProtectionIntegrated
    Residual Current MonitoringIntegrated
    Battery Reverse Polarity ProtectionIntegrated
    Anti-Islanding ProtectionIntegrated
    AC Over Current ProtectionIntegrated
    AC Short Circuit ProtectionIntegrated
    DC SwitchLevel 2
    DC Surge ProtectionLevel 3
    AC Surge ProtectionLevel 3
    Basic Parameters
    Operating Temperature Range-25~+55°C
    Relative Humidity0-95%
    Max. Operating Altitude3000m
    Cooling MethodIntelligent Air Cooling
    DisplayTouch Screen
    BMS Communication MethodRS485/CAN
    Communication InterfaceRS485/CAN
    Communication ProtocolCAN
    Weight<1500kg
    Dimensions (W×H×D)1795×1934×294mm
    TopologyNon-Isolated
    Protection LevelIP55
    Firefighting SystemAerosol
    Installation MethodFloor-mounted

    Hefei VoltaNest Energy Storage Technology Co., Ltd.

    VoltaNest is located in Hefei City, Anhui Province. As a global leading new energy enterprise, with over 20 years of experience in PV systems, VoltaNest Group provides high-quality energy storage products for residential, commercial, and utility applications. Our lithium iron phosphate (LFP) solar battery systems offer safe, long-lasting, and efficient energy storage.

    VoltaNest has won the unanimous recognition of consumers with satisfactory quality and perfect after-sales service. We can provide customized services and overseas installation services according to the needs of different customers.We can provide customized products according to customer needs. ODM and OEM orders are welcome.

    Our products are all packed in cartons or wooden boxes that meet international standards, and we ensure that all products can reach customers safely and quickly. We also support video inspection, which makes the whole process transparent and gives customers more peace of mind.

    Our products have UL, CE, UN38.3, IEC62619, MSDS and other certifications

    FAQ

    Q: Can you provide shipping services?
    A: Yes, we can handle customs clearance and door-to-door delivery.

    Q: If I have my own brand and would like custom manufacturing services, would you be able to do that?
    A: We are a leading energy storage battery manufacturer in China, providing OEM/ODM services to over 58 partners worldwide.

    Q: How to install and use?
    A: We provide installation and operating instructions and video tutorials, and we also offer overseas installation services upon request.

    Q: What if I encounter problems during use?
    A: Our products come with an extended 5-10 year warranty and a lifetime free diagnostic service.

    Q: Can I become a local distributor for your products?
